Puf Panel And Sound Proof

• Application
• Cold storage, Clean rooms, Prefabricated buildings, Roofing, Wall cladding, Ripening chambers, Modular rooms

• Breakdown Voltage
• NOT APPLICABLE Milliamperes (mA)

• Coating Type
• Polyester / SMP / PVDF color coated

• Color
• Off-white / Sky blue / Any RAL color

• Density
• 38 42 kg/m Kilogram per cubic meter (kg/m3)

• Feature
• High thermal insulation, Lightweight, Fire retardant (PIR option), Easy installation, Energy efficient, Airtight joints, Durable & corrosion resistant

• Features
• High thermal insulation Lightweight & durable Energy efficient Fire retardant option (PIR) Easy & fast installation Air-tight joints Corrosion resistant

• Heat Conductivity
• 0.021 0.024 W/mK Watt/Meter/K (w/(m.k)

• Installation Guideline
• Tongue & groove interlocking system with cam lock / fastener fixing on structure with proper sealing

• Layer
• Three Layer (Metal Sheet + PUF Insulation + Metal Sheet)

• Material
• PUF core with PPGI / GI / SS outer sheets

• Max Withstanding Temperature
• -40 C to +80 C

• Operating Temperature
• -40 C to +80 C Celsius (oC)

• Product Type
• Insulated Sandwich PUF Panel

• Size
• As per requirement (up to 12 15 meters)

• Surface Treatment
• Color coated / Galvanized / Embossed / Plain finish

• Tensile Strength
• 0.10 0.15 MPa Megapascals (MPa )

• Thermal Conductivity
• 0.021 0.024 W/mK Watt/Meter/K (w/(m.k)

• Thickness
• 30 mm / 40 mm / 50 mm / 60 mm / 80 mm / 100 mm / 120 mm Millimeter (mm)

• Usage & Applications
• Cold storage, Clean rooms, Prefabricated structures, Insulated roofing & wall cladding, Ripening chambers, Porta cabins, Modular buildings

• Warranty
• 5 10 Years (depends on sheet & coating)

• Width
• 1000 mm (effective) / 1070 mm (overall) Millimeter (mm)

• Application
• Industrial

• Color
• Different available

• Density
• 40 Kilogram per cubic meter (kg/m3)

• Feature
• Premium Quality

• Heat Conductivity
• 40 degree Calorie (th)/second/centimeter/C

• Installation Guideline
• As Suggested

• Material
• PUF

• Product Type
• puf sandwich panel

• Size
• Various Available

• Thickness
• 30-200 Millimeter (mm)

• Warranty
• 1 Year

• Width
• 1000-1200 Millimeter (mm)
